Custom Plastic Extrusion

Custom Plastic Extrusion



The custom plastic extrusion services offered by Lerner Molded Plastics has been delivering quality OEM, automotive, and consumer products to customers for over 25 years. We specialize in manufacturing single, co, and tri-extruded plastic profiles, pipes, and tubes that can be extruded to 12″ of circumscribing diameter, and cut to any custom length. We can apply a combination of materials and features to meet the requirements of food-grade or flame-retardant applications. As a UL certified molder we also operate an ISO certified facility that can accommodate production volume from prototype to high volume runs. For more information about our precision extrusion services, or our other capabilities, please contact Lerner Molded Plastics.

Custom Plastic Extrusion at Lerner Molded Plastics

(click on thumbnail to enlarge)
Custom Plastic Extrusion Services

During the plastic extrusion process, raw thermoplastic material, typically in the form of pellets, is melted and formed into a continuous profile. The extrusion process uses a rotating screw to push the melted raw material down a heated barrel that has been set to a specific temperature. The plastic then flows through a screen to remove any contaminants before passing through a die and taking on its final shape.

Many shapes and types of items are produced through this process, including pipes, tubing, sheeting, or custom-designed profiles. The extruded product can be used as-is or later fabricated into a more complex assembly by undergoing secondary processing techniques, such as punching, forming, and bending.

The Benefits of Custom Plastic Extrusion

Plastic extrusion is a high-volume manufacturing process that is used in a wide range of industries. Its cost-efficiency allows companies of all sizes to take advantage of the benefits this production process offers. These benefits include:

  • Low cost. Plastic extrusion is very low cost compared to other molding processes. This process allows waste to be reused rather than discarded, which lowers both material and disposal costs. Additionally, plastic extrusion machines operate continuously, providing 24-hour production capabilities that result in a more efficient, cost-effective process. Plastic extrusion tooling is typically significantly cheaper than tooling for other plastic manufacturing methods.
  • Flexibility and versatility. As long as the component’s cross-section remains the same, extrusion molding is capable of producing parts of many shapes, providing significant design flexibility. The extrusion process also allows for the manufacturing of parts that combine differing plastic attributes, such as soft and hard surfaces. With just a minor alteration, extrusion molding can go from producing complex shapes to plastic sheets.
  • Post-extrusion alterations. After plastic leaves the extruder, it remains hot and can be further manipulated. This allows manufacturers to alter the shape of extruded plastic using rollers, shoes, or dies to meet the specific needs of many applications.

Plastic Extrusion Applications

Since plastic extrusion is a highly versatile process, it provides adaptable solutions for applications throughout many industries. Extruded plastics are used throughout industrial and commercial applications, with some of the most common being tubing, rods, and specialty profiles.

Applications for extruded plastic tubing, rods, and specialty profiles include:

  • Medical device components
  • Deck railings
  • Fencing
  • Window and door profiles
  • Furniture
  • Automotive components
  • Children’s toys
  • Pet products
  • Decorations
  • Gaskets
  • Bearings
  • Seals
  • Bumpers
  • Windshield wipers
  • Dividers
  • And more

Plastic Extrusion Capabilities

General Custom Plastic
Extrusion Capabilities
Cut to Length
Extrusion ProcessSingle Extruded
Coextruded
Tri-Extruded
Maximum Circumscribing Circle Size12 in
MaterialHigh Density Polyethylene (HDPE)
Polypropylene (PP)
Polystyrene (PS)
ABS
Acrylic
Polyester (PET, PETG)
Polycarbonate (PC)
Extrusion Product FormProfiles
Pipe
Tube
Extrusion Features Curved
Flame Retardant
Flexible
Food Grade
Secondary ServicesIn-Line or Post Molded Secondary Assembly
Ultrasonic Welding
Part Decorating (Hot Stamping, Pad Printing, Painting)
Bar Coding and Labeling
Complete Packout Services
Warehousing Services and Drop Ship Capability
All Material, Packaging, and Components Sourcing
Complete Supply Chain Services
Product Distribution
Logistics
Engineering
Product Development
Mold Making
Tooling
Vendor Managed Inventory Programs
Kanban
Production VolumePrototype Runs to Full Production Capacity

Additional Information

Industry FocusOEM
Housewares
Toys
Automotive
Consumer Products
Intended ApplicationComponents
Consumer Products
Decorative
Firearm Components
Furniture
Hardware
Pet Products
Pressure Transducers
Toys
Window Components
Industry StandardsISO Certified
File FormatsSolidWorks
Pro-Engineer

Our Custom Plastic Extrusion Capabilities

Lerner Molded Plastics has been providing high-quality precision extrusion services for over 25 years. Specializing in single, co, and tri-extruded plastic tubes, pipes, and profiles, our capabilities include extrusions up to 12’’ in circumscribing diameter. Our plastic extrusions can be cut to any length, and we offer various materials and features to meet the requirements of flame-retardant or food-grade applications.

We have decades of experience delivering custom components that meet the demands of many industries, including OEM, automotive, and consumer products. As a UL-certified molder, Lerner Molded Plastics operates an ISO-certified facility that accommodates production volumes from prototype to high-volume runs. We also offer a wide range of secondary services, including in-line or post-molded secondary assembly, hot stamping, painting, barcoding, tooling, and more.

To get started on your custom plastic extrusion solution, or to learn more about our other capabilities, request a quote or contact us today.
